Degreasing | Derusting | Passivation


What are the benefits of the degreasing cleaning method?

The most important aspects at a glance

  • Cleaning with solvents and aqueous cleaners
  • High and low pressure cleaning
  • Manual or fully automatic cleaning
  • In combination with ultrasound and oscillation

Optionen

  • Partially automated insertion of the baskets

Reinigungsmedien

  • Water (cold/warm)
  • Caustic soda
  • Hydrocarbons

Degreasing | Derusting | Passivation - these machines from krumm-tec are interesting for you:

Always included in our standard design:

  • Individual dimensions and equipment
    available in many dimensions and designs with a width of 1000 – 4000 mm (special dimensions available on request)
  • Transparent side walls
    from safety glass

  • Supply and exhaust air
    in the working area also as floor extraction, including rear piping
  • Brushed stainless steel surface
  • Integrated lighting
    with safety glass
  • Flexible installation
    Plant mountable and mobile

Dimensions
Height: 2800 mm | Width: 1000 mm | Depth: 870 mm
working height: 950 mm +/- 50 mm
usable area: 700 x 100 mm
Weight 280 kg

Power connection
Voltage: 230 V, 50 Hz, L1, N, PE
Connected load: 0,7 kW
Power fuse: 3 A

Cleaning parameters
Compressed air: 6 bar

Dimensions
Height: 2670 mm | Width: 1450 mm | Depth: 950 mm
working height: 980 mm +/- 20 mm
usable area: 900 x 600 mm
Weight 380 kg

Power connection
Voltage: 230 V, 50 Hz, L1, N, PE
Connected load: 0,45 kW
Power fuse: 4,8 A

Cleaning parameters
Compressed air: 6 bar

Dimensions
Height: 2038 mm | Width: 1500 mm | Depth: 900 mm
working height: 950 mm +/- 20 mm
Weight: 305 kg

Power connection
Voltage: 230 V, 50 Hz, L1, N, PE
Connected load: 0,1 kW
Power fuse: 1 A

Cleaning parameters
Compressed air: 6 bar

Dimensions
Height: 2220 mm | Breite: 1600 mm | Tiefe: 950 mm
working height: 970 – 1050 mm
usable area: 630 x 1400 mm
Weight: 360 kg

Power connection
Voltage: 230 V, 50 Hz, L1, N, PE
Connected load: 0,25 kW
Power fuse: 1,15 A

Cleaning parameters
Compressed air: 6 bar

Dimensions
Height: 2220 mm | Width: 1800 mm | Depth: 940 mm
working height: 970 – 1050 mm
usable area: 2x 730 x 890 mm
Weight: 430 kg

Power connection
Voltage: 400 V, 50 Hz, L1, N, PE
Connected load: 5 kW
Power fuse: 7,2 A

Cleaning parameters
Compressed air: 6 bar

Dimensions
Height: 2800 mm | Width: 2000 mm | Depth: 870 – 950 mm
working height: 950 mm +/- 50 mm 1050 mm
usable space: 900 x 600 mm
Weight: 280 kg 625 k

Power connection
Spannung: 400 V, 50 Hz, L1, L2, L3, N, PE
Connected load: 2,7 kW
Power fuse: 6,75 A

Cleaning parameters
Compressed air: 6 bar

Workspace (WxHxD):
280 x 280 x 335 mm

Load:
100 kg

Tank capacity min./max.:
27 l

External dimension (WxHxD):
700 x 450 x 550 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
470 x 400 x 370 mm

Tank capacity min./max.:
55 l

External dimension (WxHxD):
700 x 1000 x 600 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
470 x 400 x 370 mm

Tank capacity min./max.:
55 l

External dimension (WxHxD):
700 x 1000 x 600 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
580 x 285 x 330 mm

External dimension (WxHxD):
860 x 1175 x 865 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
580 x 285 x 330 mm

External dimension (WxHxD):
860 x 1175 x 865 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
610 x 440 x 250 mm

Tank capacity min./max.:
200 l

External dimension (WxHxD):
1000 x 2580 x 1530 mm

Workheight min./max:
800 mm

Feed:
Trolley

Working space (WxHxD):
1200 x 1100 x 950 mm

Load:
540 kg

Tank capacity min./max:
550 L

Outer dimensions (WxHxD):
1000 x 2580 x 1530 mm

Working height min./max:
800 mm

Feed:
Hand, crane, forklift / cherry picker

Workspace (WxHxD):
1200 x 1100 x 950 mm

Load:
200 kg

Tank capacity min./max.:
550 l

External dimensions (WxHxD):
2000 x 1113 x 1356 mm

Workheight min./max:
1000 mm

Feed:
Hand, Crane, Lift truck / Elevating platform

Workspace (WxHxD):
1200 x 1100 x 950 mm

Load:
200 kg

Tank capacity min./max.:
550 l

External dimension (WxHxD):
2000 x 1113 x 1356 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Tank capacity min./max:
750 L

Weight:
1150 kg

Outer dimensions (WxHxD):
2515 x 2425 x 1555 mm

Working height min./max:
1000 mm

Feed:
Hand, crane, forklift / cherry picker

Workspace (WxHxD):
1200 x 1100 x 950 mm

Load:
200 kg

Tank capacity min./max.:
550 l

External dimension (WxHxD):
2000 x 1113 x 1356 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Work area (BxHxT):
2000 x 1000 x 1000 mm

Load:
200 kg

Tank capacity min./max.:
1800 L

Dimensions (BxHxT):
2550 x 1850 x 1200 mm

Work height min./max:
1200 mm

Feed:
Hand, Kran, Stapler / Hubsteiger

Workspace (BxHxT):
2000 x 1000 x 1000 mm

Load:
200 kg

Tank capacity min./max.:
1800 L

Dimensions (BxHxT):
2550 x 1850 x 1200 mm

Work height min./max:
1200 mm

Load:
Hand, Kran, Stapler / Hubsteiger

Workspace (WxHxD):
1220 x 1350 x 1220 mm

Load:
300 kg

Tank capacity min./max.:
180 / 380 l

External dimension (WxHxD):
1600 x 1800 x 1400 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1220 x 1350 x 1220 mm

Load:
300 kg

Tank capacity min./max.:
180 / 380 l

External dimension (WxHxD):
1600 x 1800 x 1400 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1050 x 640 x 920 mm

Load:
300 kg

Tank capacity min./max.:
180 / 380 l

External dimension (WxHxD):
2045 x 2115 x 1711 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1000 x 1000 x 900 mm

Load:
100 kg

Tank capacity min./max.:
120 l

External dimension (WxHxD):
1600 x 2300 x 1500 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
1800 x 1200 x 1500 mm

Load:
1000 kg

External dimension (WxHxD):
2000 x 2000 x 2040 mm

Workheight min./max.:
1000 mm

Feed:
Hand, fork lift / lifting cart

Workspace (WxHxD):
820 x 450 x 500 mm

Load:
250 kg

Tank capacity min./max.:
60 / 100 l oder Verwurf

External dimension (WxHxD):
900 x 2100 x 1050 mm

Workheight min./max.:
1000 mm

Feed:
Hand, fork lift / lifting cart

Workspace (WxHxD):
250 x 350 x 350 mm

Load:
80 kg

Tank capacity min./max.:
60–100 l

External dimension (WxHxD):
1200 x 1000 x 2200 mm

Workheight min./max.:
1100 mm

Feed:
Manually

Workspace (WxHxD):
1100 x 550 x 1100 mm

Load:
250 kg

Tank capacity min./max.:
60 / 200 l

External dimension (WxHxD):
1400 x 2100 x 1300 mm

Workheight min./max.:
1000 mm

Feed:
Hand, fork lift / lifting cart

Workspace (WxHxD):
1750 x 2500 x 1300 mm

Load:
3000 kg

Tank capacity min./max.:
100 / 300 l

External dimension (WxHxD):
1800 x 2600 x 1300 mm

Workheight min./max.:
700 / 1000 mm

Feed:
Fork lift / lifting cart

Workspace (WxHxD):
3100 x 2500 x 3500 mm

External dimension (WxHxD):
3200 x 2675 x 3870 mm

Feed:
Crane, fork lift / lifting cart

Workspace (WxHxD):
1150 x 500 x 800 mm

Load:
100 kg

Tank capacity min./max.:
60 / 150 l

External dimension (WxHxD):
1200 x 2400 x 1200 mm

Workheight min./max.:
710 / 810 mm

Feed:
Hand, fork lift / lifting cart

Workspace (WxHxD):
1350 x 950 x 800 mm

Load:
3000 kg

Tank capacity min./max.:
60 / 200 l

External dimension (WxHxD):
1400 x 2400 x 1300 mm

Workheight min./max.:
1000 mm

Feed:
Hand

Workspace (WxHxD):
1350 x 1000 x 1000 mm

Load:
250 kg

Tank capacity min./max.:
60 / 150 l

External dimension (WxHxD):
1400 x 2400 x 1300 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1300 x 950 x 900 mm

Load:
3000 kg

Tank capacity min./max.:
60 / 200 l

External dimension (WxHxD):
1350 x 2000 x 1400 mm

Workheight min./max.:
950 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1300 x 950 x 900 mm

Load:
3000 kg

External dimension (WxHxD):
1350 x 2000 x 1400 mm

Workheight min./max.:
950 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1050 x 950 x 800 mm

Load:
3000 kg

External dimension (WxHxD):
1100 x 1970 x 1450 mm

Workheight min./max.:
750 / 900 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
2150 x 1400 x 2000 mm

Load:
3000 kg

Tank capacity min./max.:
230 l

External dimension (WxHxD):
2200 x 2400 x 2000 mm

Workheight min./max.:
550 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1800 x 1200 x 1500 mm

Load:
3000 kg

Tank capacity min./max.:
200 / 250 l

External dimension (WxHxD):
2000 x 2000 x 2040 mm

Workheight min./max.:
1000 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
2150 x 1400 x 2000 mm

Load:
3000 kg

Tank capacity min./max.:
230 l

External dimension (WxHxD):
2200 x 2400 x 2000 mm

Workheight min./max.:
550 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1650 x 1400 x 2000 mm

Load:
3000 kg

Tank capacity min./max.:
230 l

External dimension (WxHxD):
1700 x 2200 x 2000 mm

Workheight min./max.:
900 / 1100 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1650 x 1400 x 2000 mm

Load:
3000 kg

Tank capacity min./max.:
230 l

External dimension (WxHxD):
1700 x 2200 x 2000 mm

Workheight min./max.:
900 / 1100 mm

Feed:
Hand, crane, fork lift / lifting cart

Workspace (WxHxD):
1650 x 1400 x 2000 mm

Load:
3000 kg

Tank capacity min./max.:
230 l

External dimension (WxHxD):
1700 x 2200 x 2000 mm

Workheight min./max.:
900 / 1100 mm

Feed:
Hand, crane, fork lift / lifting cart

External dimension (WxHxD):
4000 x 2675 x 2850 mm

Feed:
Hand, crane, fork lift / lifting cart
